Pallet Making Machine, Pallet nailing table, wood pallet corner cutter

Brand Name : SH

Model Number : WPN-1, WPN-2, WPC-7045,AWPN-1300,etc

Certification : ISO9001

Place of Origin : Shandong Province, China

MOQ : 1 SET pallet making machine

Price : USD2800-23200/SET

Payment Terms : T/T, Western Union

Supply Ability : 100sets/month

Delivery Time : within 20 days

Packaging Details : wooden pallet or iron frame packings

Name : pallet making machine

Motor Power : 2kw

Working mode : Automatic feeding and stacking

Operational mode : Pneumatic operation

Air pressure : 0.8MPA

Nail gun speed : 7 times /second.

Production efficiency : 1-2pcs /min

Number of nail guns : 3P OR 4P

Apply a nail : Less than 90mm

Warranty : 1 year

After-sales service : video technical support, spare parts

Contact Now

Automatic wooden pallet nailing machine

Model	AWPN-1300
Working mode	Automatic feeding and stacking
Operation mode	Touch screen
Operational mode	Pneumatic operation
Voltage and power	220V/ 2kw Servo motor
Air pressure	0.8MPA
Tank size	0.2 cubic
Nail gun speed	7 times /second.
Production efficiency	1-2pcs /min
Apply a nail	Less than 90mm
Number of nail guns	3P OR 4P
Weight	2000kg
Size	Host machine 166019702217mm Stacking 294520541410

Pallet Making Machine, Pallet nailing table, wood pallet corner cutter

wood pallet corner cutter

Model	WPC-7045
Power	4KW
Voltage	380V 50HZ 3phase
Cutter type	Round cutter or straight cutter,choose one
Working width	800-1350mm
Working height	70-170mm
Productivity	700-950pc/8h
Working pressure	0.6-0.7Mpa
Machine dimension	1850mm1150mm1550mm
Machine weight	About 500kg

Pallet Making Machine, Pallet nailing table, wood pallet corner cutter

Euro pallet wood chamfer machine

Model	EPWC-7050
Convey servo motor	1kw
Hydraulic motor	2.2kw
Total motor	7.2kw
Voltage	380v 50Hz 3phase
Cutter type	45° V milling cutter, left and right
Working length	600-1500mm
Working thickness	17-35mm
Working width	80-150mm
Productivity	500-700pc/h
Hydraulic pressure	0.4-0.5Mpa
Control system	Siemens
Machine dimension	44508001400mm
Packing dimension	32209201760mm
Machine weight	1040kg

Wood block multi-blade saw

Model	BM-1250
Cutting Length	1250mm
Cutting Thickness	100mm
Cutting Width	200mm
Saw Diameter	355mm
Motor	30kw
Weight	1600kg

Slot Milling Machine /Notcher Pallet Machine

Making slots on the wood boards for pallet production
Technial data

Model	WPN-1	WPN-2
Power	15kw	30kw
Material of knife	Alloy	Alloy
Capacity	600-800pics/h	1800pics/h
Processing size	Wood pallet length: max 1800mm	Wood pallet length: max 1400mm
	Wood pallet width: 160mm	Wood pallet width: max 90mm
	Wood pallet thickness:40-60mm	Wood pallet thickness: 40-60mm
	Slot depth: <45mm	Slot depth: <45mm
	Slot width: 200-230mm	Slot width: 200-230mm
Machine size	120011001200mm	230013001300mm
Machine wight	400kg	1000kg
Feature	Slot smooth, size consistent
Apply for many kinds of slots, also can customized.

Single blade type
Pallet Making Machine, Pallet nailing table, wood pallet corner cutter

Double blade type

Pallet Making Machine, Pallet nailing table, wood pallet corner cutter Images
